Lectrotab SMART TABS SX Series

Lectrotab SMART TABS SX Series - Composite SX10512

0 Review(s) Write a Review

Please select option

The SX series incorporates all of the fully automatic features of our popular SMART TABS, in addition to the rust and corrosion free benefits of molded composite materials.

Part Number: SX10512

Choose Model Number *

SX10512-70 Black SX Composite 10.5"x12"-70 (+$145.00) SX10512-90 Black SX Composite 10.5"x12"-90 (+$145.00)

The item you are trying to purchase is currently out of stock.
Please enter your name, email, and phone number below.
We will contact you as soon as this product is available.

Name: *

Email: *

Phone: *

Verification: *

Type the word above...

Quantity

Description
Special Offer
Additional Information
Feature 9
Feature 10
Feature 11
Feature 12
WARNING CALIFORNIA

SMART TABS SX Series - Composite SX10512-70 in Black

A larger version of our most popular SMART TABS SX. This heavy duty system maximizes improvements in handling, ride and fuel economy for power boats with heavier engine options and larger hull designs.

Application:

Outboard: 70 Pounds

21' - 25', 175 to 220 hp, 2 stroke
21' - 25', 150 to 190 hp, 4 stroke

I/O: 21' - 25', 4 or 6 cyl

Outboard: 90 Pounds

21' - 25', 220 to 350 hp, 2 stroke
21' - 25', 200 to 350 hp, 4 stroke

I/O: 21' - 25', 8 cyl

Features and Benefits:

Larger plates include 30% more planning surface
Plates absorb water and become more rugged over time
Increased actuator load capacity

Specifications: 70 pounds

Available in black only
Rust- and corrosion-free thermo-molded composite material
Plates include five (5) actuator mounting positions to fine-tune the system
Heavy-duty hinge design with four (4) mounting bosses
70 lb Actuators (GA5000-70X)
Not Compatible with PR500-SX Plate Retractor Kit

Specifications: 90 Pounds

Available in black only
Rust- and corrosion-free thermo-molded composite material
Plates include five (5) actuator mounting positions to fine-tune the system
Heavy-duty hinge design with four (4) mounting bosses
90 lb Actuators (GA5000-90X)

Dimensions: 70 Pounds

Trim Plate: 10.5" W x 12" L (TP10512)
Hinge: 8 3/4" L x 2 1/8" W (CH9510)

Dimensions: 90 Pounds

Trim Plate: 10.5" W x 12" L (TP10512)
Hinge: 8 3/4" L x 2 1/8" W (CH9510)

Contents: 70 Pounds

(2) TP10512 Trim Plate
(2) CH9510 Hinge
(1) HK10512 Hinge Kit
(2) GA5000-70X Actuator
Instructions

Contents: 90 LBS

(2) TP10512 Trim Plate
(2) CH9510 Hinge
(2) GA5000-90X Actuator
(1) HK10512 Hinge Kit

Warranty:

Limited manufacturer five (5) year warranty on all metal and composite components and two (2) year warranty on gas actuators. Visit www.nauticusinc.com/warranty for terms and conditions.

Made in USA
